Hi,
I need help adding this plugin to tutor that is currently deployed on my local machine:
All the plugin examples I have seen are for plugins that are used for config changes but not for adding any external plugin.
Hi @utsavjari
I think the guidance you need should be here: Installing extra xblocks and requirements
example:
tutor config save --append OPENEDX_EXTRA_PIP_REQUIREMENTS=git+https://github.com/Pearson-Advance/openedx-lti-tool-plugin.git
@feanil do you have any advice here? (installing the openedx-lti-tool-plugin)
I agree with @joel.edwards , this is just adding a new requirement.
You’ll also need to set a couple of settings, you can make a small quick plugin to do that like in this example here: Examples — Tutor documentation
1 Like
Thanks for the instructions, I have created the plugin and addded it
from tutor import hooks
hooks.Filters.ENV_PATCHES.add_item((“lms-env-features”,“ENABLE_LTI_PROVIDER: true”))
hooks.Filters.ENV_PATCHES.add_item((“lms-env-features”,“OLTITP_ENABLE_LTI_TOOL: true”))
After adding it I enabled the plugin and ran
tutor images build all
Then ran the command shared by @joel.edwards
tutor config save --append OPENEDX_EXTRA_PIP_REQUIREMENTS=git+https://github.com/Pearson-Advance/openedx-lti-tool-plugin.git
and ran
tutor images build openedx
but after running above command I am getting some error, below is the stack trace (I am unable to upload txt files on forum so adding below, everything below is the stacktrace but somehow text field is formatting it badly):
Building image docker.io/overhangio/openedx:20.0.1-indigodocker buildx build --tag=docker.io/overhangio/openedx:20.0.1-indigo --output=type=docker --cache-from=type=registry,ref=docker.io/overhangio/openedx:20.0.1-indigo-cache /home/utsav/.local/share/tutor/env/build/openedx[+] Building 9.2s (53/72) docker:default=> [internal] load .dockerignore 0.0s=> => transferring context: 2B 0.0s=> [internal] load build definition from Dockerfile 0.0s=> => transferring dockerfile: 12.42kB 0.0s=> resolve image config for docker.io/docker/dockerfile:1 0.8s=> CACHED docker-image://docker.io/docker/dockerfile:1@sha256:38387523653efa0039f8e1c89bb74a30504e76ee9f565e25c9a09841f9427b05 0.0s=> [internal] load build definition from Dockerfile 0.0s=> [internal] load metadata for docker.io/powerman/dockerize:0.19.0 1.6s=> [internal] load metadata for 1.8s=> [internal] load .dockerignore 0.0s=> importing cache manifest from docker.io/overhangio/openedx:20.0.1-indigo-cache 3.1s=> [internal] load build context 0.1s=> => transferring context: 3.79MB 0.1s=> [code 3/4] ADD --keep-git-dir=true . 2.9s=> FROM docker.io/powerman/dockerize:0.19.0@sha256:a34158d699e065609fc845e7cdc1e070f185afdbca317fe4931aaea04818f8bf 0.0s=> [minimal 1/2] FROM 0.0s=> => resolve 0.0s=> CACHED [minimal 2/2] RUN --mount=type=cache,target=/var/cache/apt,sharing=locked --mount=type=cache,target=/var/lib/apt,sharing=l 0.0s=> CACHED [production 1/37] RUN --mount=type=cache,target=/var/cache/apt,sharing=locked --mount=type=cache,target=/var/lib/apt,shar 0.0s=> CACHED [production 2/37] RUN if [ “1000” = 0 ]; then echo “app user may not be root” && false; fi 0.0s=> CACHED [production 3/37] RUN useradd --no-log-init --home-dir /openedx --create-home --shell /bin/bash --uid 1000 app 0.0s=> CACHED [production 4/37] COPY --link --from=docker.io/powerman/dockerize:0.19.0 /usr/local/bin/dockerize /usr/local/bin/dockerize 0.0s=> CACHED [code 1/4] RUN mkdir -p /openedx/edx-platform 0.0s=> CACHED [code 2/4] WORKDIR /openedx/edx-platform 0.0s=> CACHED [code 3/4] ADD --keep-git-dir=true . 0.0s=> CACHED [code 4/4] RUN git config --global user.email “tutor@overhang.io” && git config --global user.name “Tutor” 0.0s=> CACHED [edx-platform 1/1] COPY --from=code /openedx/edx-platform / 0.0s=> CACHED [production 5/37] COPY --link --chown=1000:1000 --from=edx-platform / /openedx/edx-platform 0.0s=> CACHED [python 1/4] RUN --mount=type=cache,target=/var/cache/apt,sharing=locked --mount=type=cache,target=/var/lib/apt,sharing=lo 0.0s=> CACHED [python 2/4] RUN git clone /opt/pyenv --branch v2.3.36 --depth 1 0.0s=> CACHED [python 3/4] RUN /opt/pyenv/bin/pyenv install 3.11.8 0.0s=> CACHED [python 4/4] RUN /opt/pyenv/versions/3.11.8/bin/python -m venv /openedx/venv 0.0s=> CACHED [production 6/37] COPY --link --chown=1000:1000 --from=python /opt/pyenv /opt/pyenv 0.0s=> CACHED [python-requirements 1/7] RUN --mount=type=cache,target=/var/cache/apt,sharing=locked --mount=type=cache,target=/var/lib/a 0.0s=> CACHED [python-requirements 2/7] RUN --mount=type=cache,target=/openedx/.cache/pip,sharing=shared pip install setuptools==69. 0.0s=> CACHED [python-requirements 3/7] RUN --mount=type=bind,from=edx-platform,source=/requirements/edx/base.txt,target=/openedx/edx-platfo 0.0s=> CACHED [python-requirements 4/7] RUN --mount=type=cache,target=/openedx/.cache/pip,sharing=shared pip install django-redis==5 0.0s=> CACHED [python-requirements 5/7] RUN --mount=type=cache,target=/openedx/.cache/pip,sharing=shared UWSGI_PROFILE_OVERRIDE=“xml=no” 0.0s=> CACHED [python-requirements 6/7] RUN pip install “openedx-scorm-xblock>=19.0.0,<20.0.0” 0.0s=> CACHED [python-requirements 7/7] RUN --mount=type=cache,target=/openedx/.cache/pip,sharing=shared pip install 'git+https://github 0.0s=> CACHED [production 7/37] COPY --link --chown=1000:1000 --from=python-requirements /openedx/venv /openedx/venv 0.0s=> CACHED [production 8/37] COPY --link --chown=1000:1000 --from=python-requirements /mnt /mnt 0.0s=> CACHED [nodejs-requirements 1/4] RUN pip install nodeenv==1.9.1 0.0s=> CACHED [nodejs-requirements 2/4] RUN nodeenv /openedx/nodeenv --node=18.20.1 --prebuilt 0.0s=> CACHED [nodejs-requirements 3/4] WORKDIR /openedx/edx-platform 0.0s=> CACHED [nodejs-requirements 4/4] RUN --mount=type=bind,from=edx-platform,source=/package.json,target=/openedx/edx-platform/package.js 0.0s=> CACHED [production 9/37] COPY --link --chown=1000:1000 --from=nodejs-requirements /openedx/nodeenv /openedx/nodeenv 0.0s=> CACHED [production 10/37] COPY --link --chown=1000:1000 --from=nodejs-requirements /openedx/edx-platform/node_modules /openedx/node_m 0.0s=> CACHED [production 11/37] RUN ln -s /openedx/node_modules /openedx/edx-platform/node_modules 0.0s=> CACHED [production 12/37] WORKDIR /openedx/edx-platform 0.0s=> CACHED [production 13/37] RUN pip install -e . 0.0s=> CACHED [production 14/37] RUN mkdir -p /openedx/config ./lms/envs/tutor ./cms/envs/tutor 0.0s=> CACHED [production 15/37] COPY --chown=app:app revisions.yml /openedx/config/ 0.0s=> CACHED [production 16/37] COPY --chown=app:app settings/lms/.py ./lms/envs/tutor/ 0.0s=> CACHED [production 17/37] COPY --chown=app:app settings/cms/.py ./cms/envs/tutor/ 0.0s=> CACHED [production 18/37] RUN make clean_translations 0.0s=> ERROR [production 19/37] RUN ./manage.py lms --settings=tutor.i18n pull_plugin_translations --verbose --repository='openedx/openedx-t 3.1s
[production 19/37] RUN ./manage.py lms --settings=tutor.i18n pull_plugin_translations --verbose --repository=‘openedx/openedx-translations’ --revision=‘release/teak.2’:2.852 Traceback (most recent call last):2.852 File “/openedx/edx-platform/./manage.py”, line 99, in 2.852 execute_from_command_line([sys.argv[0]] + django_args)2.852 File “/openedx/venv/lib/python3.11/site-packages/django/core/management/init.py”, line 442, in execute_from_command_line2.854 utility.execute()2.854 File “/openedx/venv/lib/python3.11/site-packages/django/core/management/init.py”, line 416, in execute2.854 django.setup()2.854 File “/openedx/venv/lib/python3.11/site-packages/django/init.py”, line 24, in setup2.854 apps.populate(settings.INSTALLED_APPS)2.854 File “/openedx/venv/lib/python3.11/site-packages/django/apps/registry.py”, line 116, in populate2.855 app_config.import_models()2.855 File “/openedx/venv/lib/python3.11/site-packages/django/apps/config.py”, line 269, in import_models2.856 self.models_module = import_module(models_module_name)2.856 ^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^2.856 File “/opt/pyenv/versions/3.11.8/lib/python3.11/importlib/init.py”, line 126, in import_module2.856 return _bootstrap._gcd_import(name[level:], package, level)2.856 ^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^2.856 File “”, line 1204, in _gcd_import2.856 File “”, line 1176, in _find_and_load2.856 File “”, line 1147, in _find_and_load_unlocked2.856 File “”, line 690, in _load_unlocked2.856 File “”, line 940, in exec_module2.856 File “”, line 241, in _call_with_frames_removed2.856 File “/openedx/edx-platform/openedx/core/djangoapps/config_model_utils/models.py”, line 23, in 2.856 from openedx.core.djangoapps.content.course_overviews.models import CourseOverview2.856 File “/openedx/edx-platform/openedx/core/djangoapps/content/course_overviews/models.py”, line 26, in 2.857 from lms.djangoapps.courseware.model_data import FieldDataCache2.857 File “/openedx/edx-platform/lms/djangoapps/courseware/model_data.py”, line 40, in 2.857 from xmodule.modulestore.django import modulestore # lint-amnesty, pylint: disable=wrong-import-order2.857 ^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^2.857 File “/openedx/edx-platform/xmodule/modulestore/django.py”, line 31, in 2.857 from xmodule.modulestore.mixed import MixedModuleStore # lint-amnesty, pylint: disable=wrong-import-position2.857 ^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^2.857 File “/openedx/edx-platform/xmodule/modulestore/mixed.py”, line 15, in 2.857 from openedx_events.content_authoring.data import CourseData, XBlockData2.857 File “/openedx/venv/lib/python3.11/site-packages/openedx_events/content_authoring/data.py”, line 15, in 2.857 from opaque_keys.edx.locator import (2.857 ImportError: cannot import name ‘LibraryCollectionLocator’ from ‘opaque_keys.edx.locator’ (/openedx/venv/lib/python3.11/site-packages/opaque_keys/edx/locator.py)
Dockerfile:194
192 | # Pull latest translations via atlas193 | RUN make clean_translations194 | >>> RUN ./manage.py lms --settings=tutor.i18n pull_plugin_translations --verbose --repository=‘openedx/openedx-translations’ --revision=‘release/teak.2’195 | RUN ./manage.py lms --settings=tutor.i18n pull_xblock_translations --repository=‘openedx/openedx-translations’ --revision=‘release/teak.2’196 | RUN atlas pull --repository=‘openedx/openedx-translations’ --revision=‘release/teak.2’ \
ERROR: failed to solve: process “/bin/sh -c ./manage.py lms --settings=tutor.i18n pull_plugin_translations --verbose --repository=‘openedx/openedx-translations’ --revision=‘release/teak.2’” did not complete successfully: exit code: 1Error: Command failed with status 1: docker buildx build --tag=docker.io/overhangio/openedx:20.0.1-indigo --output=type=docker --cache-from=type=registry,ref=docker.io/overhangio/openedx:20.0.1-indigo-cache /home/utsav/.local/share/tutor/env/build/openedx
The plugin I have used have mentioned using Olive release but I am not sure if it’s compatible with tutor’s latest version, is there anyway to find it out?
it looks like LibraryCollectionLocator was only added in version 2.11.0 of opaque-keys but the requirements of openedx-lt-tool-plugin show edx-opaque-keys==2.3.0
As you’ve mentioned, Olive is specified in the plugin so it’s possible this was intended specifically for that release and has not been updated to support latest releases. You might be able to work around this by editing the requirements so it installs the matching latest version edx-opaque-keys==3.0.0 in edx-platform, however given that this has probably not been tested in latest releases, your results may vary. My expectation is that you probably want to use another plugin that has been validated for your chosen version of Tutor
Hey, actually i tried upgrading the plugin requirements and was able to build the container, I have also setup the LTI tool in canvas, but while launching the app and on redirection to openedx I am facing a “404 not found” error. Do I need to setup anything extra in openedx to enable LTI?
Regret I’m unable to assist you further as I honestly have no experience with LTI integration nor these plugins, all the info I managed to find thus far was just from digging through the docs/code. Hopefully someone else in the community would be better positioned to assist you
No worries. thanks a lot for your help
Have you checked out the LTI docs? The landing page is here: About the LTI Component — Latest documentation and at the bottom there’s a tree of docs that may help you figure out what you need to set up
